Page #20 background imageLoading...
Page #20 background image
Mic Inputs
Mic inputs 1 / 2
Type 2 x XLR jacks, balanced
Mic E.I.N. (20 Hz to 20 kHz) -129 dBu, A-weighted
Distortion (THD+N) < 0.004%, A-weighted
Max. input level +20 dBu
Impedance 10 kΩ balanced, 5 kΩ unbalanced
Mic inputs 3 / 4
Type 2 x XLR / ¼" TRS combo jacks, balanced
Mic E.I.N. (20 Hz to 20 kHz) -117 dBu, A-weighted
Distortion (THD+N) < 0.01%, A-weighted
Max. input level
XLR: +6 dBu
TRS: +26 dBu
Impedance
XLR: 2 kΩ balanced, 1 kΩ unbalanced
TRS: 20 kΩ balanced, 10 kΩ unbalanced
Gain range -20 dB to +60 dB
Phantom power +48 V, switchable (inputs 1 / 2 only)
Line Inputs
Type 2 x ¼" TRS jacks, balanced (channels 5L / 7L)
Impedance 20 kΩ balanced, 10 kΩ unbalanced
Gain range -20 dB to +60 dB
Distortion (THD+N) 0.005%, A-weighted, 0 dB gain, 0 dBu out
Max. input level +22 dBu
Guitar (Hi-Z) Inputs
Type 2 x ¼" TRS jacks, balanced (channels 6R / 8R)
Impedance 2 MΩ balanced, 1 MΩ unbalanced
Distortion (THD+N) 0.005%, A-weighted, 0 dB gain, 0 dBu out
Max. input level +19 dBu
Channel EQ
Low ±15 dB @ 20 Hz, shelving
Low mid ±15 dB @ 300 Hz
High mid ±15 dB @ 1.5 kHz
High ±15 dB @ 20 kHz, shelving
Monitor Outputs
Type 2 x ¼" TRS jacks, balanced
Impedance 75 Ω, balanced
Max. output level +14 dBu
Main Outputs
Type 2 x XLR jacks, balanced
Impedance 150 Ω, balanced
Max. output level +14 dBu
Phones Output
Type 1 x ¼" TRS jack, stereo
Max. output level +18 dBm / 40 Ω
Footswitch Input
Type 1 x ¼" TRS jack (tip / ring normally open)
Function congurable
FX mute / Tap tempo or
Snapshot load next / previous
Input / Output and Processing
Frequency range 10 Hz to 22 kHz (+0/-1 dB)
Dynamic range, analog in to analog out Typ. 108 dB
I/O latency 0.6 ms
Signal processing 32-bit VFP (Vector Floating Point)
A/D - D/A conversion 24-bit / 48 kHz
Dynamic range 114 dB
Number of input processing channels 10 input channels, 4 fx return channels
USB Audio Interface
Interface type USB 2.0
Connector Type B
Bit depth 24-bit / 48 kHz
Channels 10 out / 2 in
Bluetooth
Frequency range 2402 MHz ~ 2480 MHz
Channel number 79
Version Bluetooth spec 4.0 compliant
Compatibility Supports A2DP 1.2 prole
Max. communication range 12 m (without interference)
Max. output power 8 dBm
Power Supply / Voltage
Connector Micro-USB
Power supply 5 VDC 2A
Power consumption Max. 10 W (typ. 5 W)
Dimensions / Weight
Dimensions (H x W x D)
48 x 229 x 172 mm
(1.9 x 9.0 x 6.8")
Weight 1.4 kg (3.1 lbs)
Specications
38 39Quick Start GuideFLOW 8
