20
GUITAR LINK UCG102
6 SPECIFICATIONS
GUITAR IN
Connector ¼" TRS
Input Impedance (High) 250 kΩ
Input Impedance (Low) 400 kΩ
PHONES OUT
Connector 1/8" TRS stereo jack
Output impedance approx. 50 Ω
Max. output pegel -2 dBu,
2 x 3.7 mW @ 100 Ω
USB 1.1
Connector type A
DIGITAL PROCESSING
Converter 16-bit converter
Sample rate 32.0 / 44.1 / 48 kHz
POWER SUPPLY
USB
connection 5 V , 100 mA max.
DIMENSIONS/WEIGHT
Dimensions
(H x W x D) 24.6 mm x 95.6 mm x 50.8 mm
0.97" x 3.75" x 2.00"
Cable length 150 mm
Weight 0.092 kg
SYSTEM REQUIREMENTS (PC / MAC)
Windows XP, Pentium 700 MHz or Athlon XP 1.33 GHz,
256 MB RAM
Mac OS X v10.3.x, G4 733 MHz, 512 MB RAM
DRIVER
Windows BEHRINGER USB AUDIO
Mac OS X Core Audio
6 SPECIFICATIONS
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from
time to time to existing products without prior notice. Specifications and appearance may differ from those listed or illustrated.
