Remove all unused cables from the MS-1.
Set the controls 1 to 8 to the position shown in the right hand column of this table.
Set all the other faders, knobs and switches shown in the photo.
Preparation
Make sure your MS-1 has been powered on for at least 30 minutes, and that it is situated in a place where the
temperature will not change drastically during calibration.
Calibration Procedure
1
2
4
5 6
7
8
3
No. Control Set to
1 LFO RATE M
2 WAVE FORM
3 GLIDE M
4 RANGE 2’
5 MAIN
6 SUB OSC 2 OCT DOWN
7 VCA GATE
8 ENVELOPE GATE
No. CV type Description
1 Internal CV Calibrates the internal CV
2 Output CV Tunes the CV output
3 External CV Compensate oscillator oset for external CV in
Follow all steps in the order in which they are presented.
