Behringer NEUTRON Customer Support Bulletin

Synthesizers and Samplers
NEUTRON
page 4 of 7page 4 of 7
In the Command Window, enter the SysEx command to be sent to the Neutron. For ASSIGN out calibration at 1 V,
the command is: F0 00 20 32 28 7F 10 20 F7
In the Command Window drop-down menu, select Send SysEx. The Sysex command will be sent to the Neutron.
Both 8' octave range LEDs will be ashing to indicate the Neutron is in ASSIGN out 1 V calibration mode.
Measure the voltage on the patch cable attached to the ASSIGN out and adjust until it reads 1 V +/- 0.001 V.

Behringer NEUTRON Specifications

General

Product type	Analog synthesizer
Product color	Red
Sound effects	Overdrive
Volume control	Rotary
Built-in speaker(s)	No
Keyboard number of keys	0
Maximum polyphony (notes)	1
Power source type	DC
MIDI in	Yes
6.35 mm (1⁄4-inch) output	2
