Behringer POLY D - PITCH WHEEL Calibration Procedure; Start Calibration Routine; Calibrate PITCH WHEEL Max;Min Positions

page 2 of 10
985-40000-01084 Rev.A
2021-02-03
Condential, for internal use only. Not to be reproduced.
page 2 of 10
Synthesizers and Samplers
POLY D
Operation:
Start Calibration Routine
1. Press and hold button ”KYBD + STEP”, then power on POLY D.
2. When all the LEDs are running (during the rst 3 seconds after power on), press button “3” to start the
calibration routine.
3. Power LED will blink RED.
Follow all steps in the order in which they are presented.
Start PITCH WHEEL Calibration
1. Press button “1” to calibrate PITCH WHEEL.
2. Button “1” LED will light and region A LEDs will indicate current PITCH WHEEL position.
