Behringer U-CONTROL UCA222 User Manual

10 U-CONTROL UCA222 User Manual
(5) OUTPUT – Connect to a speaker system using stereo RCA
cables to monitor the audio output from the computer.
(6) INPUT – Connect desired recording signal using audio
cables with RCAconnectors.
(7) OFF/ON MONITOR – With the MONITOR switch OFF,
theheadphone output receives the signal from the
computer over the USB port (same as the RCA output
jacks). With the MONITOR switch ON, the headphones
receive the signal connected to the RCA INPUT jacks.
(8) USB CABLE – Sends information to and from your computer
and the UCA222. It also provides power to thedevice.
4. Software Installation
• This device requires no special setup or drivers, just plug it
into a free USB port on a PC or Mac.
• The UCA222 comes with a free version of Audacity editing
software. Thiswill help make the transfer process quick
and simple. Simply insert the CD into your CD-ROM
drive and install the software. The CD also contains VST
plug-ins, ASIO drivers and various freeware.
◊ Note – When the UCA222 is bundled with other
BEHRINGER products, the included software may
vary. In the instance that the ASIO drivers are not
included, you may download these from our website
at behringer.com.
5. Basic Operation
The UCA222 provides an easy interface between your
computer, mixer and monitoring system. Follow these steps for
basic operation:
1) Connect the UCA222 to the computer by plugging
the USB cable into a free USB port. The power LED
will light automatically.
2) Connect the audio source that is to be recorded,
such as a mixer, preamp, etc.to the INPUT stereo
RCAjacks.
3) Plug a pair of headphones into the ⁄" PHONES jack
and adjust the volume with the adjacent control.
Youmay also monitor the output by plugging a
pairof powered speakers into the OUTPUT stereo
RCA jacks.
4) You may also send the stereo signal in digital audio
format (S/PDIF) to an external recording device via
the OPTICAL OUTPUT using a Toslink ber opticcable.

Behringer U-CONTROL UCA222 Specifications

General

Type	-
Proper use	What is the intended application of the product?
Sample rate	48 kHz
Product color	Red
Frequency range	10 - 22000 Hz
Audio (L/R) in	2

Weight and Dimensions

Depth	88 mm
Width	60 mm
Height	22 mm
Weight	100 g
