Behringer U-CONTROL UCA222 User Manual

12 U-CONTROL UCA222 User Manual
Recording device
Fiber optic cable
RCA OutputsRCA Input
Computer USB
B3031A
Active Monitor Speakers
HPM1000
V-AMP 3
Recording with a preamp such as the
V-AMP 3:
Preamps such as the V-AMP 3 provide a great way to record a
wide selection of high-quality guitar sounds without the hassle
of placing a mic in front of a conventional amp. They also allow
you to record late at night without tempting your roommates
or neighbors to strangle you with your own guitar cable.
• Plug a guitar into the instrument input of the V-AMP 3
using a standard ¼"instrument cable.
• Connect the stereo ¼" outputs on the V-AMP 3 to the
stereo RCA inputs on the UCA222. This will likely require
adaptors. You may also use the stereo RCA to ¼" TRS cable
that is included in the V-AMP 3/UCA222 package bundle
to connect from the V-AMP 3 headphone output to the
UCA222 RCA inputs.
• Plug the USB cable into a free USB port on your computer.
The POWER LED will light up.
• Adjust the output signal level on the V-AMP 3.
• Set the recording program to record input from the UCA222.
• Press record and wail!

Behringer U-CONTROL UCA222 Specifications

General

Type	-
Proper use	What is the intended application of the product?
Sample rate	48 kHz
Product color	Red
Frequency range	10 - 22000 Hz
Audio (L/R) in	2

Weight and Dimensions

Depth	88 mm
Width	60 mm
Height	22 mm
Weight	100 g
