behringer Multi-Functional 48-Point 3-Mode Balanced Patchbay
Important Safety Instructions
Terminals marked with this symbol carry electrical current of sufficient magnitude to constitute risk of electric
shock.
Use only high-quality professional speaker cables with ¼” TS or twist-locking plugs pre-installed. All other
installation or modification should be performed only by qualified personnel.
This symbol, wherever it appears, alerts you to the presence of uninsulated dangerous voltage inside the
enclosure – voltage that may be sufficient to constitute a risk of shock.
This symbol, wherever it appears, alerts you to important operating and maintenance instructions in the
accompanying literature. Please read the manual.
To reduce the risk of electric shock, do not remove the top cover (or the rear section). No user serviceable parts
inside. Refer servicing to qualified personnel.
To reduce the risk of fire or electric shock, do not expose this appliance to rain and moisture. The apparatus
shall not be exposed to dripping or splashing liquids and no objects filled with liquids, such as vases, shall be
placed on the apparatus.
These service instructions are for use by qualified service personnel only. To reduce the risk of electric shock
do not perform any servicing other than that contained in the operation instructions. Repairs have to be
performed by qualified service personnel.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.

Behringer ULTRAPATCH PRO PX3000 Specifications

General

Product color	Gray

Weight and Dimensions

Depth	93 mm
Width	482.6 mm
Height	44.5 mm
Weight	1800 g
