Behringer XENYX X2442USB - X1832 USB Rear Panel Connections; XENYX X1832 USB Live;Recording Setup

Page 12 of 17
XENYX X2442USB
X2222USB / X1832USB
X1622USB / X1222USB
X1204USB / 1204USB
XENYX X1832USB
Bass
Guitar
B412DSP Loudspeakers
E-Drums
Keyboard
DI100
Main Out R
Main Out L
XM8500 Mics
HPS3000
Electric
Guitar
V-AMP 3
Acoustic
Guitar
Laptop
XENYX X1832USB Live/Recording Setup
X1832USB Rear Panel
IEC power
socket
Power
switch
Phantom
Power switch
USB/Audio
Interface port
Main Outputs,
XLR balanced
Sub 1 & 2 Outputs,
¼" TS unbalanced
Control Room Out,
¼" TS unbalanced
Channel 1-6
Inserts
Main Outputs,
¼" TS
unbalanced
