Beijer Electronics VICPAS EXTER Series - Introduction; General

Introduction
Beijer Electronics, MA00757A 7
2 Introduction
This manual describes how to maintain EXTER series operator terminals.
The functions available in the configuration tool depend on which operator
terminal model is used. The manual is divided into the following sections:
– Safety Precautions
– Introduction
– Hardware
– Software
– Environmental Aspects
2.1 General
The HMI range offers four different sized keypad-operated models and five touch
screen models. The different operator terminals are listed in the table below:
Operator
Termina l
Description Drawings
EXTER K30
(also referred to
as BEPP K30)
240 x 64 pixels, display with keypad Outline drawing
Panel cut-out
Tex t s t r i p
EXTER K60c
(also referred to
as BEPP K60)
5.7" display with keypad Outline drawing
Panel cut-out
Tex t s t r i p
