4. Technical Data
Parameter X2 pro 10 - B2
Front panel, W×H×D 292 × 194 × 7 mm
Cutout dimensions, W×H 275 × 177 mm
Mounting depth 45 mm (145 mm including clearance)
Standalone mounting VESA 75 × 75
Note: Maximum screw length for VESA mounting is 4 mm. Usage of
longer screws may lead to damage.
Front panel seal IP 65
Rear panel seal IP 20
Touch screen material Polyester on glass, ITO film, resistive
Frame overlay Autoflex EBA 180L
Touch screen operations 1 million finger touch operations
Reverse side material Powder-coated aluminum
Frame material Powder-coated aluminum
Weight 1.65 kg
CPU i.MX6 DualLite
Dual ARM Cortex-A9 Core
1.0GHz
512 kB L2 cache
Serial ports StandardD-sub (9 Pin, female)
COM1: RS-232 with RTS/CTS
COM2: RS-422/RS-485
COM3: RS-485
1×RS-232 Rx/Tx with RTS/CTS and 1×RS-422 or 2×RS-485 or 1x CAN
2.0B.
Ethernet LAN A 10/100 Mbit Base-T (shielded RJ45 with LEDs)
Ethernet LAN B 10/100 Mbit Base-T (shielded RJ45 with LEDs)
USB 2 × USB Host 2.0, max output current 500 mA
Supports up to USB 2.0 High Speed
External storage media 1 × SD card
Flash memory
(application memory)
1.5 GB SSD (eMMC)
Memory RAM 1 GB (DDR3)
NVRAM N/A
LED 1 × Multi color
Real time clock Yes
Battery BR 2032 lithium battery
replaceable
Technical Data
2023-09 14 Beijer Electronics, MAEN220
