Beko 42" - AV3 Board Block Diagram; Image Processor

HDTV as Option
Block Diagram AV3 Board
Teletext Engine
SDA5550M
Video Decoder
(ADC)
VPC3230D
Flash ROM
512 KByte
S RAM
256 KByte
Sound Processor
(ADC/DAC)
MSP3410G
Video Matrix
TEA6415C
Video Matrix
TEA6415C
Audio Matrix
VGA/HDTV In
1x analog & 1x DVI
Sound Input
3x Cinch & 2xScart
Sound Output
1xCinch & 2xScart
Speakers Out
Cinch
Audio Amplifier
LM1876
RF-Tuner
4046FM5
Video Input
1x Cinch , 1x MiniDIN, 2x Scart (incl. RGB)
Display Port 48Bit
4x 74LVTH16244
Image Processor
Main CPU
PW171B
Video De-Interlacer
SDA9415
(embedded RAM)
VGA ADC
& DVI Receiver
AD9887
Flash ROM
1 MByte
RS 232
DSUB
BLOCK DIAGRAM AV3 BOARD
-44-
