1 – coolant level sensor; 2 – engine harness extender; 3 – SCR connecting harness; 4 – electronic foot pedal to control en-
gine operation mode at direct motion; 5 – handle for manual control of engine operation mode; 6 – information display; 7 – integrated
electronic panel (IEP); 8 – protection and switching unit; 9 – test jack ; 10 – engine electronic control unit; 11 – electronic foot pedal
to control engine operation mode on reverse; 12 – ambient temperature sensor; 13 – connecting harnesses; 14 – sensor of water
presence in fuel filter.
Figure 3.2.1 – Engine electronic control system.
