Belden Hirschman RSPS20 User Manual

Installation RSPS20/25
Release 09 12/2019
19
1.3.2 Rear view
6 Supply voltage connection
alternatively,
depending on
device variant
Supply voltage with
the characteristic
value:
CC
 2 voltage inputs for redundant power supply
 2-pin terminal block
Supply voltage with
the characteristic
value:
M9 or K9
 1 voltage input
 3-pin terminal block
7 Connection for the signal contact
1 Slot for the SD card
2 Thumb screw
1
2
