Belden Hirschmann HC4900 - Data Display Elements Explained; Icon Key Symbols Definition

- 12 -
Data display：
1. Load moment percentage bar graph
2. Load moment percentage displayed value
3. OM code
4. Reeving
5. Rotary angle
6. Outrigger mode
7. Rid pressure
8. Piston pressure
9. Operating height
10. Time (error code will be displayed when defect)
11. Wind speed
12. Fixed jib boom length
13. Main boom length
14. Main boom angle
15. Fixed jib boom angle
16. Rated load capacity
17. Actual load
18. Working radius
19. Enforced icon (OEM special requirement)
Icon Key symbols definition：
a. Function setting key (refer to 5.1)
b. OM setting key (refer to 5.2)
c. Reeving setting key (refer to 5.3) OM setting key
d. Error code information key (refer to 5.4)
e. Alarm off key (refer to 5.5)
