Belden Hirschmann HC4900 - 10. OM List

- 35 -
10. OM List
OM
Operating
area
Outrigger
status
Code of
setting*
Displayed
code
Main boom OM
360° Fully extend
1
0001
360° Half extend 1001
360° Fully retract 2001
360° None 3001
Front None 3101
Creep
None
4101
Rooster Sheave
OM
360° Fully extend
2
0002
360° Half extend 1002
360° Fully retract 2002
360° None 3002
Front None 4002
Creep
None
4102
1
st
jib section 0°
360°
operation
Fully extend
11 0011
1
st
jib section 20° 12 0012
1
st
jib section 40° 13 0013
2
nd
jib section 0° 21 0021
2
nd
jib section 20° 22 0022
2
nd
jib section 40° 23 0023
 Code of setting refers to the number required to be inputted during OM
Setup to set the code for the respective OM listed in the table.
