Installation RSP20/25/30/35
Release 18 09/2021
7 Disassembly
7.1 Removing the device
Proceed as follows:
 Disconnect the data cables.
 Disable the supply voltage.
 Disconnect the terminal blocks.
 Disconnect the grounding.
 To remove the device from the DIN rail, press the device downwards and
pull it out from under the DIN rail.
WARNING
ELECTRIC SHOCK
Disconnect the grounding only after disconnecting all other cables.
Failure to follow this instruction can result in death, serious injury, or
equipment damage.
