3 Device description
3.1 Device unclean side (US)
1 Door drive (behind the panel)
2 Wash compartment doors made of double-layer safety glass
3 Operating panel
4 Main switch (with EMERGENCY OFF function)
5 Service panel
6 Location type plate
7 Transfer trolley
8 Rack
9 Automatic wash compartment doors
10 Door safety switching strip
