Operating Manual WD 425E
Rev. 1.1, LS Page 16 of 34 78563_E rev 1.1.doc
3.2 Program Start
The machine may be launched by program keys P1 to P12 or by automatic program detection on the rack
(Configuration ON). With automatic program recognition, any program may be overwritten manually by
means of program keys, provided that the door is open.
The program will launch only after door is completely closed.
Display first shows program name, subsequently status indication as described here:.
P2
W ● ● _ _ X 13 Min
Cleaning 36 °C
P2 Program N° (P1 – P12)
W ●_ _ X Program step status, e.g. step 1 of 3
W ● ● _ _ X Status indication, step 2 of 4.
End marking "
W _ _ X" represents the number of steps in the respective program.
13 Min Remaining run time or remaining program time.
Actual value plus recorded last value / 2. In case of interruption, value is ignored.
Cleaning Current step
36 °C Temperature of wash liquid or of drying air at input wash channel.
3.3 User Identification
Importing Names – N°. by way of the keyboard or importing Name of user by means of the code reader for
the batch documentation.
With active user ID, and with open door, the following message, i.e. interrogation is found on display:
User Name or N°?
--
The unit either reads a 2-digit of the 6 program keys from 11 - 66 or a text / number by means of the barcode
reader. The respective number (e.g. 36) or name is passed on to the printer or the digital documentation sys-
tem, it is also associated with the respective batch. A program can be launched only after the respective in-
puts are complete, otherwise the SW persists with the interrogation.
Input by keyboard:
IN case of input of N° 66, text „No ID “ is passed on.
IN case of input by barcode reader, it is preferable to establish a list with N° associations with respective
names.
Example:
N° Name
11 Sr. A. Muster
12 Sr. H. Mueller
66 No ID
