➧ Automatic image adjustment ..................................
You can adjust the image settings (such as brightness,
contrast, image position, phase, etc.) manually or by
using the LCD monitor’s automatic image adjustment
feature. This will adjust the image parameters to their
optimal settings for the current graphics mode. Press
SELECT/AUTO (
i
in fi g. 4) to launch the automatic
adjustment. The process will take a short while until
completed.
➧ Setting the volume directly .....................................
You can adjust the speaker volume of the integrated
audio system directly by pressing the
or buttons
(
g
and
h
in fi g. 4) while the OSD menu is inactive.
Next, press the
button to increase the volume or the
button (
g
and
h
in fi g. 4) to decrease it.
➧ Shortcut for adjusting brightness and contrast...
You can adjust brightness and contrast directly by press-
ing the
or buttons (
d
and
e
in fi g. 4) while the
OSD menu is not displayed. Next, press the or
buttons (
d
and
e
in fi g. 4) to adjust the brightness or
the or buttons (
g
and
h
in fi g. 4) to adjust the
contrast.
➧ Disabling the sound (MUTE) ...................................
You can mute sound playback by pressing the
or buttons (
g
and
h
in fi g. 4) while the OSD
menu is not displayed. Next, press the
button to
mute the sound or the
button (
d
and
e
in fi g. 4) to
reactivate it.
BASIC SETUP
The OSD menu is a window on your screen that allows
you to view and change display settings. To change an
OSD setting:
1. Press the MENU button (
c
in fi g. 4) to display the
OSD menu on the screen.
2. There are a total of 5 OSD submenus divided by
categories. Select the desired submenu by pressing
the OSD button
or (
d
and
e
in fi g. 4; see
section “OSD Menu Functions”).
3. Press the OSD button SELECT/AUTO (
i
in fi g.
4) to activate the selected function or associated
submenu.
4. If you selected a submenu, now select the subfunc-
tion you want using the or OSD buttons (
d
and
e
in fi g. 4).
5. Set the desired value using the OSD button
or
(
g
and
h
in fi g. 4).
6. Press the SELECT/AUTO (
i
in fi g. 4) button to
save the setting. Repeat steps 2–5 to make further
adjustments as needed.
7. The OSD menu automatically disappears if no
changes are made for more than 45 seconds (default
setting). The current settings will be saved. You can
close it manually by pressing the MENU button (
c
in fi g. 4).
Figure 4. Monitor features
IMAGE SETTINGS USING THE OSD MENU
7
6
5
4
3
2
1
ENGLISH
➧ Monitor setup under Windows
®
9x/ME/2000
and XP:
If using the monitor under Windows
®
9x/ME/2000 or XP,
we strongly recommend installing the Belinea confi gura-
tion fi le. You can obtain this fi le from your Belinea dealer
or download it from the MAXDATA FTP server at ftp.
maxdata.com. Here, click the “Belinea_Treiber_Driver”
directory and download the Belinea.inf and README_
Belinea.TXT fi les. Follow the installation instructions in
the README_Belinea.TXT fi le.
➧ Monitor setup under Windows
®
NT 4.0:
Under Windows
®
NT 4.0 no separate setup file is
required. Select the vertical frequency and the number
of colors directly from within the “Settings” Æ “Control
Panel” Æ “Display” Æ “Settings” menu.
CONFIGURATION
