Belinea 2025 S1 - Operating Instructions - 6
ENGLISH
OSD MENU FUNCTIONS
Brightness/Contrast
Controls the picture’s contrast, brightness.
Other
Displays the current graphic resolution including vertical
frequency as well as letting you choose from among the
following settings:
Language: Selects the OSD menu language: English,
French, German, Spanish, Italian, Dutch, Russian,
Polish.
OSD Position: Controls the OSD menu’s position.
Information: There is an optional OSD window (On/
Off) that displays the newly adjusted screen resolution
settings.
Reset: Restores factory display settings.
Resolution Notice: The optimum resolution for this
monitor is 1400 × 1050.
ENGLISH
OTHER
LANGUAGE ENGLISH
OSD POSITION
INFORMATION OFF
RESET RUN
1400x1050@60 Hz
PRESET MODE
Color
Regulates the color temperature settings. Activate the
OSD window using the MENU button. Go to the COLOR
option by pressing the
or buttons. Press the
SELECT/AUTO button and
or to select R (red),
G (green) or B (blue). Then you can change the color
values using the
or buttons.
You can also choose one of the preprogrammed color
temperatures 9300 K, 6500 K oder sRGB (D65).
Position
Regulates the horizontal and vertical position of the
image. Activate the OSD window using the MENU button.
Go to the POSITION option by pressing the
or
buttons. Use the SELECT/AUTO button and
or
to set the vertical position and
or to set the hori-
zontal position.
Tracking
Clock: Sets up the internal clock. Larger values make
the displayed image appear wider; smaller values make
it appear compressed.
Phase: Adjusts the internal clock’s time lag in order to
optimize the screen image.
Autoswitch: This option allows you to decide if the
Auto Adjustment function should take effect after each
change to the monitor’s resolution.
To Next Page
