Belkin BASIC F7D1101 - Installing and Setting Up the Adapter; Windows Vista and 7 Installation Process

10
OVERVIEW
(a) Protective Cap
The cap is provided to protect the USB connector
during transportation. Remove the cap before inserting
the Adapter to your computer’s USB port.
(b) Power/Activity LED
Lights when the Adapter is powered on and flashes when it is active.
(c) USB Connector
Part of the Adapter that fits into your computer’s USB port.
(b)
(a)(c)
