MACHINE INFORMATION
MACHINE SPECIFICATIONS
Intended Use Of Machine
The intended use of this machine is the bulk
handling and transport of material.
Machine Operation Temperature
Range
The intended safe operating temperature range of a
standard machine is -20 ˚C to 45 ˚C. The machine
can be operated down to -40 ˚C but fitment of
specialised equipment (arctic kit) may be
necessary. Consult your local BELL Equipment
dealer concerning this.
Consult the tyre manufacturer when operating
ambient temperatures are expected to fall outside
the intended safe operating temperature range of -
40°C to 45°C.
Fuel Specification
The optimum fuel for the Bell B35E to B60E has a
Sulphur content of 500 ppm or less for the Stage 3A
machines and 50ppm or less for the Stage 4/Tier 4f
machines.
Wheels
Tyre size B35E 6X6 ADT 26.5R25
Tyre size B40E ADT 29.5R25 (875/65R29
optional)
Tyre size B45E ADT 29.5R25 (875/65R29
optional)
Tyre size B50E ADT 875/65R29 (29.5R25
optional)
Tyre size B60E 4x4 ADT Front : 875/65R29 & Rear :
24.00R35
Axles
Machine Front Middle Rear
B35E ADT 25E6HA 25E6HB 25U6HA
B40E ADT 25E6HA 25E6HB 25U6HA
B45E ADT 25I6HA 25I6HB 25U6HA
B50E ADT 27E6HA 27E6HB 27E6HA
B60E ADT 27E6HA N/A D106PL429-
NLB
Suspension System
Front (B35E, B40E & B45E)
Type Semi-independent axle
movement, leading A-frame
supported on Hydro-pneu-
matic suspension struts.
Option: Electronically
controlled adaptive
suspension with ride height
adjustment.
Front ( B50E & B60E)
Type Semi-independent axle
movement, leading A-frame
supported on Hydro-pneu-
matic suspension struts. The
suspension is an electroni-
cally controlled adaptive sus-
pension with ride height
adjustment.
Rear (B35E, B40E, B45E & B50E)
Type Pivoting walking beams to
equalise load distribution,
connected to the axles via
laminated rubber suspension
blocks.(4 supporting links per
axle)
Option: Comfort Ride
suspension walking beams
with two-stage sandwich
block.
Rear (B60E)
Type Trailing arm cradle supported
by Hydro-pneumatic suspen-
sion struts with an additional
lateral stabiliser.
Transmission
ADT Model
B35E Allison 4500 ORS
B40E Allison 4700 ORS
B45E Allison 4700 ORS
B50E Allison 4800 ORS
B60E Allison 4800 ORS
