Bell B45E 6X6 ADT User Manual

OPERATION
OPERATING INSTRUCTIONS
NOTE
If no driver access code has been pro-
grammed, the engine will crank as
soon as the Ignition On/Engine Start
switch is pressed while the ignition LED
is flashing.
5. If the machine does not start then press the
Ignition Off/Engine Stop switch (3) to stop
cranking, if you hold down the Ignition On/En-
gine Start switch then the engine will crank ON-
LY while you have the switch de pressed. The
automatic engine crank will turn off after 15 sec-
onds if the engine has not started.
NOTE
Engine will not start by towing or
pushing.
If there is a service due within the next 50 machine
hours, there will be a single "pop-up" message
displayed on the CDU screen (on ignition-on), with
a buzzer beep to alert the operator that a service is
due. This "pop-up" will display the number of hours
left until the service is due.
If the machine surpasses the service due machine
hours, without the service being done (or the
service done signal being re-set (by Service
Personnel) then the ignition-on "pop-up" message
will display ”Service X hours Overdue”
To switch the engine OFF, press the stop button on
the Switch Module which is the RED Button.
The Display will indicate the turbo is spooling down
– Allow this to complete.
Under no circumstances should the Master Switch
be switched off after the ignition is turned off.
The Display will show a “Message” not to turn the
Isolator / Master Switch Off as a the system will
enter a Purge Cycle.
Once the System has completed the purge cycle of
the Adblue system the Back up alarm will sound
three times and the ignition will switch off
Automatically.
Check Daily Service Information
A Daily Checks menu is accessible at the CDU to
encourage thorough daily service checks.
Perform this check at the start of every shift after
performing the Daily Walk Round Checks.
Shutting Down Engine
Never stop the engine from high idle. This will cause
damage to the turbocharger and the engine. Do not shut
the engine down with the ignition still ON using the bat-
tery isolator switch. This could cause error codes to be
logged from electrical modules that need ignition se-
quence shut down before battery power is disconnected.
Allow 10 seconds delay from ignition OFF to battery
disconnect switch OFF.
1. To stop the engine, press the Ignition Off/En-
gine Stop switch. Keep the service brake pedal
depressed until the engine shuts down.
2. As the engine speed decreases, the transmis-
sion will go into Neutral and the park brake will
be applied (with out the option of releasing it
again).
3. After the park brake is applied the system will
go into a "Turbo Spin-Down" mode and the en-
gine will be turned off after a certain amount of
time (the time depends upon machine usage,
two minutes is the maximum time taken).
4. During this shut- down, time a count down timer
will be shown on the CDU and the buzzer will
beep once every second.
NOTE
In case of an emergency press and
hold the Ignition Off/Engine Stop
switch, this will shut down the engine
and the ignition power. In this case an
Emergency Shut Down. code will be
logged continuously on the next ignition
cycle until a full Turbo Spin Down has
been counted.
NOTE
The Turbo Spin Down protects the en-
gine components by allowing for proper
lubrication and for all temperatures to
stabilise before the engine shuts down.
If the machine is stopped overnight ensure the bat-
tery isolator switch is turned to the OFF position.
