10
ATTACHING THE TRAILER TO BIKE
Remove rear wheel bolt. Attach quick release mounting bolt to the wheel.
Re-tighten rear wheel bolt. Attach quick release pin to the trailer arm and latch
securely. Figure 8A, 8B and 8C.
CONVERSION KIT ASSEMBLY
The conversion kit consists of a rear handle and front
wheel assembly that attach to the trailer to convert it
for walking use.
The front wheel attaches to the hitch arm. Place front
wheel through hitch arm hole, place grenade pin and
secure the pin clamp. Figure 9A.
The handle bar attaches to the rear side support frame
uprights with clamps. Loosen the knobs, slide the
clamps through the portholes provided in the fabric,
around the frame and tighten. Tug on the handle bar to
make certain that it is tight on the frame. Figure 9B.
Remove the conversion kit wheel and handle bar
before towing the trailer. The wheel can catch on the
ground and the handle bar can hook onto things
unexpectedly while turning.
8A
9A
8B
9B
8C
