26
Bellfires
English
Instructions for use and installation instructions
Figure 11: Vertical roof-mounted outlet with bend
Appliance: Distance X (*) Distance Y
1
(*) Distance Y
1
+ Y
2
(*)
(min.-max.) (min.-max.) (min.-max.)
All appliances 0 - 3,0 m 1,0 - 10,0 m 1,0 - 10,0 m -
16
23
Y
2
X
10, 11, 12, 13
14, 15
Y
1
4
1
28
23
23
17
24
(*) : (Y
1
+ Y
2
) : X > 2 : 1
(vertical to horizontal ratio (or 45° upwards) is always at least 2 to 1)
ALL SIZES INCLUDE THE LENGTH OF THE ROOF OR WALL TERMINATION
Item descriptions:
see 3.4.2
Assemble
restriction plate
