Bellfires
English
Instructions for use and installation instructions
Appliance: Distance Y
(min.-max.)
All appliances, except… 2,0 - 11,0 m -
... Jersey
... Vertical Bell Small
2,0 - 11,0 m Width: B = 30 mm
... Vertical Bell Tunnel
... Horizon Bell Medium
FLEXIBLE CONCENTRIC FLUE Ø100 mm - Ø150 mm SYSTEM CONNECTION
POSSIBILITIES
Figure 12: Vertical chimney outlet using an existing lined chimney
(Flexible Ø100 mm and/or rigid Ø100 mm / Ø150 mm)
1
4
28
32
18
23
25
26
29
7
5
29
30
10, 11, 12, 13
Y
ALL SIZES INCLUDE THE LENGTH OF THE ROOF OR WALL TERMINATION
Item descriptions:
see 3.4.2
Assemble
restriction plate
