28
Bellfires
English
Instructions for use and installation instructions
Figure 13: Vertical chimney outlet using a lined chimney with a bend > 45°
(Flexible Ø100 mm and/or rigid Ø100 mm / Ø150 mm)
(*) : (Y
1
+ Y
2
+ Y
3
) : X > 2 : 1
(vertical to horizontal ratio (or 45° upwards) is always at least 2 to 1)
Y
2
Y
1
10, 11, 12, 13
> 45°
X
Y
3
32
18
30
29
5
7
29
26
25
23
28
4
1
Appliance: Distance X (*) Distance Y
1
(*) Distance Y
1
+ Y
2
+ Y
3
(*)
(min.-max.) (min.-max.) (min.-max.)
All appliances 0 - 3,0 m 1,0 - 10,0 m 1,0 - 10,0 m -
ALL SIZES INCLUDE THE LENGTH OF THE ROOF OR WALL TERMINATION
Item descriptions:
see 3.4.2
Assemble
restriction plate
