36
Bellfires
English
Instructions for use and installation instructions
SMART - BELL
RIGID CONCENTRIC FLUE Ø100 mm - Ø150 mm SYSTEM CONNECTION
POSSIBILITIES AND “SNORKEL”
REAR CONNECTION
ALL SIZES INCLUDE THE LENGTH OF THE ROOF OR WALL TERMINATION
Figure 21: Horizontal wall outlet “Snorkel”
Appliance: Distance X
(min.-max.)
Smart Bell 0 - 0,5 m -
X
37
2
Item descriptions:
see 3.4.2
Assemble
restriction plate
