35
Bellfires
English
Instructions for use and installation instructions
ALL SIZES INCLUDE THE LENGTH OF THE ROOF OR WALL TERMINATION
SMART - BELL
FLEXIBLE CONCENTRIC FLUE Ø100 mm - Ø150 mm SYSTEM CONNECTION
POSSIBILITIES
REAR CONNECTION
(**) : (Y
1
+ Y
2
+ Y
3
) : (X
1
+ X
2
) > 2 : 1
(vertical to horizontal ratio (or 45° upwards) is always at least 2 to 1)
Figure 20: Vertical chimney outlet using an existing unsound lined
chimney or when the chimney is unlined; with a bend >45
o
(Flexible Ø100 mm - Ø150 mm and/or rigid Ø100 mm - Ø150 mm)
2
4
28
5
7
32
30
29
18
> 45°
Y
1
X
1
Y
2
Y
3
X
2
Appliance: Distance X
1
(**) Distance X
2
(**) Distance Y
1
+Y
2
+Y
3
(**)
(min.-max.) (min.-max.) (min.-max.)
Smart Bell 0 - 0,5 m 0 - 2,0 m 1,0 - 11,0 m -
Item descriptions:
see 3.4.2
Assemble
restriction plate
