64
Bellfires
English
Instructions for use and installation instructions
3.5.5.3 Marble pebbles
1 Place the ceramic mat on the burner in such a way that the holes in the mat are in
line with the burner openings.
2 Spread the pebbles over the whole burner bed (burner and grid around the burner).
Make sure that the pilot light remains free.
Figure 29: Marble pebbles-set NATURAL GAS
IMPORTANT: Open area, in order to ensure free
accessibility of the pilot flame to the burner.
Figure 30: Marble pebbles-set PROPANE
IMPORTANT: Open area, in order to ensure free
accessibility of the pilot flame to the
burner.
Keep the burner
orifices unblocked
