Installing Your Cooker
900 installation built in (high level)
1. Remove the fixing screws from the polythene bag on the top of the appliance, but leave
the appliance in the base tray packaging until you are ready to install it.
Note:
When removing the appliance from the base tray packaging care should be taken
to ensure the outer frame trim is not damaged.
2. (i) When installed in a typical 600mm deep built in housing unit, the false back should
be removed from the housing unit, to provide the necessary depth for installation.
(ii) When the false back is removed, it is normally the case that the support shelf for
the appliance leaves a gap between the back edge and the wall of approximately
80mm.
(iii) If no gap occurs between the back edge of the shelf and the wall behind the unit,
we recommend that a gap of at least 30mm is made by shortening the shelf.
3. The appliance is designed to fit into a standard 600mm wide housing unit, with mini-
mum internal dimensions as shown.
Please note that all sizes are nominal - some variation is to be expected
.
46
