Bellini BC604T - Appliance Installation Guide; Installation Requirements; Preparation and Fitting

5
Installing The Appliance
Important:
z There must be a minimum distance of 65mm from rear wall of cabinet
Preparation
z Remove any dust from the benchtop directly surrounding the cut hole to ensure there is a clean surface.
z Remove the protective paper film from the adhesive strip that is secured to the bottom of the glass
surface.
z Position the cooktop into the hole in the benchtop and press down firmly to ensure a secure fit to the
benchtop.
1. Benchtop
2. Ceramic Cooktop
3. Adhesive Seal
2
1
3
