Bematech I-150 Programming Guide

Start Configuration
End Configuration
2
I-150 PROGRAMMING GUIDE
Settings and Programming
Scan selected barcodes in this manual to perform setup and programming of the
handheld imaging barcode scanner. Decoding options and interface protocols can be
tailored to a specific application.
Setup parameters are stored in non-volatile memory in the scanner and are retained
even when power is off. Setup parameters change only when you reset them. You may
need to hide adjacent code patches with your hand when scanning.
Programming operation steps
To program each scanner parameter, scan the setup barcodes in the following sequence.
1. Scan "Start Configuration" barcode to initiate set up.
2. Scan the barcodes for desired configuration.
3. Scan "End Configuration" barcode to confirm the setup.

Bematech I-150 Specifications

General

Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D
Read rate (max)	280 reads/s
Yaw reading angle	-25 - 25 °
Tilt reading angle	-55 - 55 °
Pitch reading angle	-75 - 75 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, Industrial 2 of 5, Interleaved 2 of 5, MSI, Plessey, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Not supported
Cable length	1.4 m
Standard interfaces	USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	20 - 50 °C
Operating relative humidity (H-H)	5 - 98 %
Certification	EMC CE & FCC DOC, VCCI IEC 62471
Product color	Black
Housing material	Plastic
International Protection (IP) code	IP52
Input voltage	5 V
Power consumption	140 mA

Weight and Dimensions

Depth	121.6 mm
Width	66.3 mm
Height	162.8 mm
Weight	200 g
