2.3 - Loading the Paper Roll
Notes: Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper
glued to the core because the printer cannot detect the paper end correctly.
1. Turn off power switch.
2. Make sure that the printer is not receiving data; Otherwise, data may be lost.
3. Open the paper roll cover by pushing down the cover-open push button.
4. Remove the used paper roll core if there is one inside.
5. Insert new paper roll as shown.
6. Adjust the paper end sensor:
Set the lever according to the
diameter of the paper roll, pushing
upward (towards S) if the paper roll
has a smaller diameter (standard
roll: 12.5 mm + / - 5) and push
down (toward L) if it has a larger
diameter.
