S.p.A. BL200/BL 250
18
TECHNICALDETAILS
FORTHEENGINEFEATURESSEETHEENGINEINSTRUCTIONBOOKLETDELIVEREDWITHTHEMACHINE.
• Acousticpressuretotheoperator’sear:LpA=81dB(A)
• VibrationtohandlebarwithweightingISO.5349value:from8,98m/sec².
Testcondition:1,6Mtinthemiddleofthehandlebar
Theenginefittedonthistillerhavefollowingfeatures:
• Exhaustguard
• Recoilstarter
• Dryairfilter
• LUBRICATION4STROKESENGINE:seeinstructionmanualoftheengine.
• Quantityofengineoil:seeinstructionmanualoftheengine.
• Fuel:unleadedpetrol.
• Safetydeviceforboth
forwardandbackwardgearstoppingthetiller.
• Thetransmissionhasgotdoublebelttransmission(frontandreverse)fortheengineandagreasedchainforthetiller.
• Thehandlebarcanbeadjustedin2verticalpositions(Fig.n°2).
• Thetilleris50cmwide(Fig.n°9).
• Thegear‐box
isscrewed(Fig.n°3Ref.”A”).
• Theridgerisadjustableinthreedifferentpositions(Fig.n°3Ref.“B”).
Alltheidentificationreferences(codenumber,engine,weight,power)areprintedonthenumberplateonthemachine(Fig.n°4Ref.
“A”).
INSTRUCTIONSFORMOTORHOEASSEMBLY
Themachineispackedinaboxwithfollowingdimensions:
◊
WIDTH:70cm ◊ LENGHT:51cm ◊ HEIGHT:70cm
• Takethemachineoutofthecartonbox.
• Fittherearspurinitsplaceusingthedeliveredpin.
• Fitthehandlebaronthesupportthroughthetwoscrewsandthenutwhicharealreadyfittedonthehandlebar.
• Fitthefronttransferwheeltoits
holder,alreadyfittedontheframe,byusing thescrew,thebushandthenut(Fig.n°5Ref.”A”).
• Duringthetransportthehandlebarcanbeleftunassembledbyremovingbothscrewsthatfixittothehandlebarsupport
