OPERATION AND MAINTENANCE MANUAL
Page 7 of 22
Implements
The machine can be operated as well with the following implements:
SICKLE BAR, PLOUGH, MOWER, SNOW THROWER, TRAILER, SHREDDER, REVERSIBLE PLOUGH,
LEVELLING BLADE, ROTARY SWEEPER.
For other implements, please get in touch with the producing firm.
To attach and use the different implements, refer to the specific manual.
Remark on attaching implements
When attaching implements, you should follow the following instructions.
 operation to be performed while the machine is switched off and well stable;
 operation to be performed only by trained and informed staff;
 only use implements compatible with the machine and following the instruction
provided by the producing firm;
Picture 2 – Attaching implements
put the safety plate of
the implement under the
rocker arm, on the internal
side of the lever
Plate
Rocker
arm
Centring rings
Tighten the screws
with a proper spanner,
gradually and alternating
the screws.
Danger of bruis
ing
and
manual load handling
If the implement
is too heavy, you should
perform the operations in two or using
adequate means, and following the proper
instructions
N.B.: The trailer must be
attached in a particular place
(shown in the picture above),
different from the power
takeoff
attach the implement
properly, being careful that the
centring rings join together
Point for
attachment
