Benchmark 5125-016 - Upper Handle Bar Assembly Parts; Lower Handle Assembly Parts

25
Key # Part # Part Name Quantity
26 36010109 Male Terminal 3
27 3419510401027001 Connecting Line 4 1
28 34402000501027001 Connecting Line 5 1
29 3422710101032001 Micro Switch 1
30 3392000101030001 Gasket 1
31 33CC0170101 Spring 1
32 3422550401027001 Cable 1
33 315230010104700 Belt 1
34 33DB600301011 Bearing 1
35 33SFCDC008250101 Hex Bolt 3
36 3122550101023001 Bearing Sleeve 1
37 3122550301049001 Motor Seat 1
Upper Handle Bar Assembly
1 3450000101032001 Switch 1
2 3250000301060001 Switch Spring 1
3 3150000401023001 Cable Sheath 1
4 3152200201081001 Elastic Pipe 1
5 3150000101069003
Unlock Button Spring
1
6 3181000101053001
Switch Box Left Cover
1
7 3150000601053002 Switch Box Fixing Plate 1
8 3150000201058007 Switch Unlock Button 1
9 3150000201157003 Switch Board Seat 1 1
10 3250000201030001 Switch Spring 1
11 3150000201069003 Switch Box Right Cover 1
12 33SBAQA004160101 Screw 13
13 3252300301057001 Power On Hoop 1
14 3150000501023001 Cushion (Foam) Handle 1
15 3222550101057001 Upper Push Rod 1
16 3252300201057001 Switc
h Lever 1
17 3150000201049002 Tie Rod Fixed Seat 1 1
18 3150000401049003 Switch Trigger Seat 2 1
19 3250000401060001 Reed Switch Knob 1
20 3150000301049001 Tie Rod Fixed Seat 2 1
21 3252300101003001 Self-Propelled Zipper - Up 1
22 3152300201072001 Power Connector 1
23 33SADDC006350101 Bolt 1
