Benchmark 5125-016 - Parts List; Motor Assembly Parts

5125-016
40V MAX BRUSHLESS LAWN MOWER
24
PARTS LIST
WARNING: When servicing, use only original equipment replacement parts.
The use of any other parts may create a safety hazard or cause damage to the
brushless lawn mower.
Any attempt to repair or replace electrical parts on this lawn mower may create
information, call the Toll-free Helpline, at 1-866-349-8665 – Friday from 9am
to 5pm Eastern Standard Time.
Always order by key number.
Key # Part # Part Name Quantity
Motor Assembly
1 3122550401069001 Transparent Cover 1
2 3122550101053001 Plate 1
3 3181000101053001 Cable Clamp 1
4 3100810201039001 Battery Pack Upper Bracket 1
5 3100810101039001 Battery Pack Under Bracket 1
6 3100810101049001 Inserting Seat 2
7 3417820101027001 Internal Wiring 1 1
8 3122550101049001 Battery Holder 1
9 33SBAQA005200101 Screw 12
10 3122550201049001 Pedestal 1
11 33SBAQA006200101 Screw 4
12 3422550101004001 Motor 1
13 33SACQC006080101 Screw 1
14 3222550101031001 Belt Sheave 1
15 33SBAQA004160101 Screw 10
16 3222550101138001 Pin 1
17 3222550101060001 Spring 1
18 3122550201053001 Sleeve 1
19 3122520101056001 Security Key 1
20 3422550101092001 Controller 1
21 36010108 Female Terminal 3
22 36040101 Double Hole Male Terminal Sleeve 1
23 36040103 Single Hole Male Terminal Sleeve 1
24 36040102 Double Hole Bushing 1
25 36040104 Single Hole Socket Sleeve 1
