Split Control Handle
The control handle is used to move the wedge up and down to split logs. The control
handle has three positions: Forward, Neutral, and Reverse. See the “operation”
section for instruction.
Manual Canister
Keep manuals safely in the canister.
Beam Lock Bracket
The beam lock bracket is used to secure the beam in the horizontal position.
Lifting Handle
The lifting handle is included for easy transition from horizontal to vertical.
2” Ball Hitch Coupler
The coupler hitch is at the end of the tongue and attaches to a tow ball for
transportation purposes.
Log Stripper
The log stripper is designed to remove any partially split wood from the wedge. This
may occur while splitting large diameter wood or freshly cut wood.
Log Catcher
A log catcher can be mounted to the beam in minutes. It is used to hold a split log.
Beam Lock Bracket
Pull outward the lock pin and lift up the lifting handle to transit the beam position
from horizontal to vertical.
The engine switch has two positions. OFF - engine will not start or run. ON - engine
will start and run.
Recoil Starter Handle
The handle is used to start the engine.
) - use this position to service, transport,
or store the unit. ON (
) - use this position to run the unit.
