23
TRANSPORTING
MOVING BY HANDS
The log splitter is heavy. It can crush and cause serious injury if it rolls out of
control or tips over.
Follow the instructions below for safely moving the log splitter.
1. Make sure the log splitter is locked in the horizontal position with latch rod
before moving.
engine running.
2.
and reduces the chance of fuel leakage. Refer to the engine manual for fuel
valve location.
3. Lock the support leg in the DOWN position before you move the log splitter.
4. Move the log splitter by hand to desired work site.
Never operate through the relief valve for more than 5 seconds.
Never allow anyone to sit or ride on the log splitter.
Never transport cargo or wood on the log splitter.
TOWING BY VEHICLE
1.
from flooding the engine.
2. Check the tires to ensure they are fully inflated to
30 PSI for proper functionality.
Do not over inflate tires. Serious injury can occur
if tire explodes.
When seating a bead after repair, do not exceed 30 PSI.
Pressures higher than 30 PSI can cause the tire and
wheel to rupture and explode.
3. Make sure hitch is in good working order.
4. Check safety chains. Two safety chains must be
used while towing. Cross safety chains under the
coupler, allowing only enough slack for vehicle turns.
5. Pull out the lock lever and put the support leg in the
UP position, then release the lever and make sure
the leg is secured.
6. Tow the log splitter carefully to desired work site.
Be aware of the added length of the splitter.
Never tow this log splitter over 70 km/h (45 mph). Faster speeds may result in
loss of control.
Drive slowly and take extra caution when traveling over rough terrain.
If towing on a public road, make sure to comply with all local and provincial
towing requirements. It is the sole responsibility of the purchaser to obtain
licensing, trailer lights, safety chains, or signage as needed to comply.
