Benchmark 5240-552 - Parts List

5240-552
25 TON GAS-POWERED LOG SPLITTER
28
PARTS LIST
WARNING:
When servicing, use only original equipment replacement parts. The use of any
other parts may create a safety hazard or cause damage to the log splitter.
Any attempt to repair or replace electrical parts on this log splitter may create a
safety hazard unless repairs are performed by a qualified technician.
Customer Service / Tech Support 1-866-206-0888.
Key# Part # Description Qty
1 5240-552-1 Clevis Pin Assy. 1
2 5240-552-2 Cylinder 1
3 5240-552-3 Elbow Fitting 1 1
4 5240-552-4 Tube 1
5 5240-552-5 Fitting 1
6 5240-552-6 Valve Assembly 1
7 5240-552-7 Elbow Fitting 2 1
8 5240-552-8 Elbow Fitting 1 1
9 5240-552-9 Nipple 1/2 NPT 1
10 5240-552-10 Hex Nut M12x1.75 9
11 5240-552-11 Lock Washer, M12 9
12 5240-552-12 Wedge, 7in. 1
13 5240-552-13 Hex Bolt, M12x75 1
14 5240-552-14 Beam 1
15 5240-552-15 Log Catcher 1
16 5240-552-16 Support Arm Left 1
17 5240-552-17 Support Arm, Large Left 1
18 5240-552-18 Hex Nut, M10 8
19 5240-552-19 Lock Washer, M10 8
20 5240-552-20 Flat Washer, M10 12
21 5240-552-21 Support, Right 1
22 5240-552-22 Lock Nut, M8 4
23 5240-552-23 Flat Washer, M8 20
24 5240-552-24 Rubber Damper 4
25 5240-552-25 Hex Bolt, M10x30 8
26 5240-552-26 Support Arm, Large Right 1
27 5240-552-27 Wheel, 4.8x8 in. 2
28 5240-552-28 Pivot Bracket 1
29 5240-552-29 Slotted Pin 1
