2.2 CONTROL PANEL
BG4650E Control Panel
1. Power Switch
2. Electric Start
3. Low Oil Light
4. Remote Start Ready Light
5. Startup Battery Wall Charger Port
6. Maintenance Hour Meter
7. Remote
8. 120V 30A (TT-30)
9. 120V 30A (L5-30)
10. Ground Connection
11. 30A Breaker
12. 120V 20A (5-20)
13. 20A Breaker
1
2
3
4
5
6
7
8
9
10
11
13
12
