BENDIX MC-30 TRAILER ABS CONTROLLER User Manual

9
Your trailer has two wheel speed
sensors and one ABS modulator that
is plumbed for axle control.
The MC-30
™
controller you have
installed is currently confi gured for
4S/2M side control.
Provide power to the MC-30
™
controller
and verify the current configuration
using the LEDs or blink codes.
4S/2M Side
Hold magnet in place for 20
seconds.
The LEDs will begin to roll as the
installed sensors and modulators are
detected.
2S/1M Dolly-Axle
With the LEDs rolling, continue to hold
the magnet in place for an additional
20 seconds. (Total of 40 seconds)
The LEDs begin to fl ash as the ABS
control toggle activation occurs.
Remove magnet.
2S/1M Axle
Verify the new confi guration using
the LEDs or blink codes.
4S/2M Side to 2S/1M Axle
CHART 7 - EXAMPLES OF SELF-CONFIGURATION AND ABS CONTROL TOGGLE (1 of 2)
Your dolly or steer axle has two
wheel speed sensors and one ABS
modulator that is plumbed for axle
control.
The MC-30
™
controller you have
installed is currently confi gured for
2S/1M axle control.
Provide power to the MC-30
™
controller
and verify the current configuration
using the LEDs or blink codes.
2S/1M Axle
Hold magnet in place for 20
seconds.
The LEDs will begin to roll as the
installed sensors and modulators are
detected.
2S/1M Axle
With the LEDs rolling, continue to hold
the magnet in place for an additional
20 seconds. (Total of 40 seconds)
The LEDs begin to fl ash as the ABS
control toggle activation occurs.
Remove magnet.
2S/1M Dolly-Axle
Verify the new confi guration using
the LEDs or blink codes.
2S/1M Axle to
2S/1M Dolly-Axle
