11
Pin Pin Name Function
Pin Size
(Area)
X2.1 PRESSURE_SENS_1 Pressure signal (left sensor)
.5 mm2
X2.2 PRESSURE_SENS_2 Pressure signal (right sensor)
X2.3 PRESSURE_SENS_GND Pressure sensor GND
X2.4 PRESSURE_SENS_SUPPLY Pressure sensor supply
X2.5
X2.6
X2.7
X2.8
X2.9
X2.10 VEH-CANL Vehicle CAN Low
X2.11 VEH-CANH Vehicle CAN High
X2.12 SYS-CANL System CAN Low
X2.13 SYS-CANH System CAN High
X2.14
X2.15
X2.16 COIL_CURRENT_A Output current (5A)
X2.17 COIL_CURRENT_B Output current (5A)
X2.18
X2.19 WL1 Warning Lamp
2.5 mm
2
X2.20 TRM-15 Ignition / Terminal 15
X2.21 SWITCH1 Input Switch for LKAS
X2.22 TRM-30A Ubat / Terminal 30A
X2.23
X2.24 SWITCH1_GND Input Switch GND
X2.25 TRM-31A GND / Terminal 31A
CONNECTOR PIN IDENTIFICATION
Table 2 – Connector Pin
