Page #3 background image
3
Figure 3 – Control Piston Cover Screws
Figure 2 – Tie Wrap Location
Tie Wrap
(Indicates repair
is complete)
Bendix
®
SR-5
™
Identication
Hole
Trailer
Supply
(Red)
Service
(Blue)
SR-5 Valve
Surelok
Supply
(Red)
Figure 4 – Piston Cover Air Line Connections
Figure 5 – Check Valve Passage
A
D
B
C
A
Control
Piston
Cover
Control
Piston
Cover
Control
Piston
Cover
Screws
Check Valve
Passage
Figure 6 – Cover Seal
Control
Piston
Cover
Cover
Seal
Spring
Piston
Figure 7 – Piston and Spring
This port must remain
open. Do not install
the check valve here.
