When removing the lift from shipping angles, pay close attention as the columns can slide and can cause injury. Be
careful when cutting steel banding material as items may become loose and fall causing personal harm or injury.
Prior to removing the pallets make sure the posts are held securely by a fork lift or some other heavy lifting device.
PCL-18B PARTS INVENTORY
Be sure to take a complete inventory of parts prior to beginning installation.
Description Qty
Column Assembly 4
Carriage Assembly 4
Fork Arm Weldment 8
Displacement Sensor Cover 4
Control Box Assembly 4
Motor Cover Assembly 4
Parts Box (Packing List Enclosed) 4
Hydraulic Jack 4
Hydraulic Power Unit 4
Displacement Sensor
Cover
Control Box
Assembly
Hydraulic Jack
Motor Cover
Assembly
Carriage
Assembly
Column
Assembly
Fork Arm
Weldment
