9
PCL-18B
Maximum Column Capacity Each Column 18,000 Lbs. / 8,165 Kg
Conguration Sold in sets of 2, 4 or 6 columns
Min. Column Height 97.5” / 2,572 mm
Maximum Lifting Height 71.5” / 1,889 mm
Length Lifting Fork 13.6” / 360 mm
Overall Length / Depth 47.5” / 1,206 mm
Width Inside Lifting Fork / Min. 9.5” / 241 mm
Width Inside Lifting Fork / Max. 22.7” / 576 mm
Overall Width 44” / 1,160 mm
Turning Circle 40” / 1,016 mm
Column Weight Each 1450 lbs. / 657 kg.
Lifting Speed 85 Seconds
Motor / 2HP * 208-240 V 50/60 Hz, 3 Phase
* Special Voltages Available Upon Request
The design, material and specications are subject to change without notice.
SECTION 3
(LAYOUT)
