SP-7XE/F Full-Rise Scissor Lift 12 P/N 5900010 — Rev. B3 — September 2023
Model SP-7XE SP-7XEF
Mounting Style Surface mount Flush mount
Lifting capacity 7,000 lbs. / 3,175 kg
A Maximum height raised
(no blocks)
70.5 in. / 1,790 mm
B Individual Platform length
62.5 in. / 1,590 mm
B1 Extended Platform length
74 in. / 1,880 mm
C Individual Platform width
21.75 in. / 550 mm
D Total length
: 165 in. / 4,190 mm
(includes Drive-up Ramps)
: 106 in. / 2,692 mm
(no Drive-up Ramps)
E Distance between Platforms
38 – 44 in. / 968 – 1,114
mm
38 in. / 968 mm
F Lowered height
6.5 in. / 161 mm
N/A
(Top of Platform to
be flush with floor)
G Max distance to Console*
Up to 39.25 in. / 999 mm
Safety Lock Positions 8
Lifting time ≈45 seconds
Motor**
220 VAC, 50/60 Hz, 1 Ph
Operating Pressure at Max. Load 3,060 psi
* With the supplied Hydraulic Hoses.
**Special voltages available upon request.
Specifications subject to change without notice.
