SP-7XE/F Full-Rise Scissor Lift 4 P/N 5900010 — Rev. B3 — September 2023
Table of Contents
Introduction 4 Operation 50
Shipping Information 5 Maintenance 58
Safety Considerations 5 Troubleshooting 60
Components 8 Wiring Diagram 62
FAQs 10 Labels 64
Specifications 10 Parts Diagram 66
Installation Checklist 13 ALI Store 76
Installation 15 Maintenance Log 77
Introduction
This manual describes the SP-7XE and SP-7XEF, which are full-rise, frame-engaging lifts that feature
an open-center design that provides full under-Vehicle access. They can be installed at ground level or
recessed (SP-7XEF “flush mount”), frequently over a service pit. Flush mount models do not use Drive-
up Ramps, but they do require a recessed surface. The installations for both units are similar. When
the instructions differ, they will be identified by model number.
Both models raise Vehicles up to 7,000 lbs. / 3,175 kg.
More information about the full line of BendPak products is available at bendpak.com.
⚠ DANGER Be very careful when setting up, operating, maintaining, or repairing this equipment;
failure to do so could result in property damage, product damage, injury, or (in very
rare cases) death. Make sure only authorized personnel operate this equipment. An
authorized technician must perform all repairs. Do not make modifications to the
unit; this voids the warranty and increases the chances of injury or property
damage. Make sure to read and follow the instructions on the labels on the unit.
This manual is mandatory reading for all users of SP-7XE/F Series Lifts, including anyone
who installs, operates, maintains, or repairs them. Always keep this manual on or near
the equipment.
Technical support and service is available from your dealer, on the Web at
bendpak.com/support, by email at support@bendpak.com, or by phone at
(800) 253-2363, option 7, then 4.
Online chat is also available at www.bendpak.com click the chat icon.
Scan this QR Code for up-to-date information and videos on the SP-7XE/F Lift
series.
